Double-Head Wood Pallet Block Making Machine

May - 06
2016

Double-Head Wood Pallet Block Making Machine

thoyu

Double-head wood pallet block making machine is designed to produce pallet block, which is for the transportation pallet. The final product could get the E1 grade. The pallet feet can be solid without a hole in the middle and also can be hollow.

1. It could recycle the wood waste efficiently.

2. Easy to operate. One person could handle 3 machines.

3. Saving the production cost and enhancing the process of automation.

How does wood pallet block making machine work?

1. Hydraulic cylinder provides high pressure and pushes the piston to extrude and mold the materials.

2. The heating of the heating plate at the high temperature promotes the solidification and molding of urea-formaldehyde glue.

3. Cutting according to certain length (usually around 1.2 meters).

4. After cooling, cutting the long wood strips of half-finished products to the final size.

The advantages of wood pallet block making machine

A. Free fumigation. The block is made by hot pressing, so it is “Export Ready”.

B. It could recycle the wood waste efficiently.

C. Easy to operate. One person could handle 3 machines.

D. Saving the production cost and enhancing the process of automation.

E. One machine could make two different block sizes.

Raw materials of wood pallet block making machine

1. Urea-formaldehy glue.

2. Wood shavings, wood sawdust, small wood chip, and other wood waste materials (the moisture content is about 10-12%).

Block sizes of wood pallet block making machine

Normally 90*90 mm, 90*100 mm, 100*100 mm,80*90 mm. If you have special requirements, we could customize while, it ranges from 75 mm to 145 mm.

Final wood pallet block

  1. Free fumigation and free quarantine.
  2. Insect prevention, protection against termites and do not easy to burn.
  3. Meeting the E1 grade.
  4. Customized sizes are available.

Parameters of wood pallet block making machine

Model Length and width of block Power (kW) Production efficiency(m³/24 hours) Dimension with saw (m) Weight (kg)
TYD

75-145 mm

22.26 4-6 8*0.7*1.5 1500
